Fair & expo
Small Animal Pens
pB Cattle Tie panels
pB Cattle Tie panels
- All Small Animal panels and gates are available in 41" and 48" heights.
- All gates have a 7' tall frame.
- All components constructed A-513 high tensile steel tubing with a 50,000 psi yield strength.
- All units are fabricated of 1.5", 14 gauge and 16 gauge steel.
- All units interlock with self-contained permanently attached drop pins.
- Gate latches also consists of self-contained drop pins.
- Available in standard gray powder coat finish, custom color powder coat finish, pre-galvanized, or hot-dipped galvanization.
- Available with 3" upright spacing or 4.1875" upright spacing.
- Feed Rod and Bedding Rail are available options.
- Custom design available
pB Cattle Tie panels
pB Cattle Tie panels
pB Cattle Tie panels
- All Cattle Tie Panels components are constructed from 1.5", 14 gauge high tensile steel tubing with a 50,000 psi yield strength.
- All joints are saddle cut for maximum strength.
- Frame height is 7' of Cattle Tie Panel and Alley Control.
- Top interior rail of Cattle Tie Panel is 48" tall with 40" tie positions.
- All units interlock with self-contained permanently attached drop pins.
- Available in standard gray powder coat finish or custom color powder coat finish.
- Arena Panels interchange with Cattle Tie Panels.
- 3 Styles to choose from.
pB Arena Panel
pB Cattle Tie panels
Panel Base (PB)
- Arena Panels interchange with Cattle Tie Panels.
- All Arena Panels components are constructed from 1.5", 14 gauge high tensile steel tubing with a 50,000 psi yield strength.
- All joints are saddle cut for maximum strength.
- Arena Panel and Alley Control height is 7'
- All units interlock with self-contained permanently attached drop pins and receivers.
- Available in standard gray powder coat finish or custom color powder coat finish.
Panel Base (PB)
Portable Horse Stalls
Panel Base (PB)
- Substantially reduce labor needs.
- Movable with forklift.
- Transportable for easy storage.
- Self standing for setup and teardown
- Interchangeable panels.
- Removable filler caps.
- Can be completely covered by bedding or dirt.
- Set on any flat surface.
- Set up in multiple configurations.
Portable Horse Stalls
Portable Horse Stalls
Portable Horse Stalls
- All components constructed A-513 high tensile steel tubing with a 50,000 psi yield strength.
- All joints on framework are saddle cut for maximum strength.
- All units interlock with self-contained permanently attached drop pins.
- Gate latches also consists of self-contained drop pins.
- All units are 6' 10.5" tall and available in 10' or 12' lengths.
- 48" doors are secured with spring loaded latches.
- Lower part of stalls include .75" BB Plyform inserts.
- Standard gray powder coat finish.
Wyoming horse Stalls
Portable Horse Stalls
Portable Horse Stalls
- All components constructed A-513 high tensile steel tubing with a 50,000 psi yield strength.
- All joints on framework are saddle cut for maximum strength.
- All units interlock with self-contained permanently attached drop pins.
- Gate latches also consists of self-contained drop pins.
- All units are 6' 10.5" tall and available in 10' or 12' lengths.
- 48" doors on rollers and secured with flip over latches.
- Lower part of stalls include .75" BB Plyform inserts.
- Standard gray powder coat finish.
Rodeo Arenas
bucking chutes
bucking chutes
- Standard gray and red powder coat finish or choose your custom powder coat finish.
- Design, delivery, and set-up available.
bucking chutes
bucking chutes
bucking chutes
- Standard gray powder coat finish or choose your custom powder coat finish.
- Multiple options to choose from.
roping chutes
bucking chutes
Weighing Systems
- Standard red finish or choose your custom powder coat finish.
- 3 sizes to choose from and accessories.
Fair & Expo Price List
FAIR & EXPO CATTLE TIES PRICE LIST
Panel Base
CALL
- Available with fill or no fill.
- 10' L x 12" W x 12" H
- Empty weight is 450 lbs.
- Filled weight is 700 lbs.
- Designed to make the PB Arena Panel, PB Tie Panel "A", and PB Tie Panel "B" self supporting.
- Forklift pockets standard.
- Can be anchored if needed.
PB Arena Panel
$556.00
- Standard 6' Height
- DOES NOT INCLUDE LUMBER
PB Arena Panel Kicker
CALL
- Optional
- Standard 6' Height
- For added stability
PB Cattle Tie Panel "A"
$702.00
- 1.9" OD 16 gauge tubing
- Ties are set for every 40" at 57" high.
- 2x lumber fill added durability.
- Cables across the uprights allow exhibitors to hang signs.
PB Cattle Tie Panel "B"
$702.00
- 1.9" OD 16 gauge tubing
- Ties are set for every 40" at 65" high.
- 2x lumber fill added durability.
- Cables across the uprights allow exhibitors to hang signs.
PB Cattle Tie Panel End "A" & "B"
$410.00
- 1.9" OD 16 gauge tubing
- Lumber fill to retain bedding.
Houston Cattle Tie Panel
$416.00
- 1.5" OD 16 gauge tubing
- Ties are set for every 40".
- .75" BB Plyform on bottom to retain bedding.
Houston Cattle Tie Panel End
$410.00
- 1.5" OD 16 gauge tubing
- .75" BB Plyform on bottom to retain bedding.
Houston Cattle Tie Panel Alley Control Frame
CALL
- 1.5" OD 16 gauge tubing
- Connects to Houston Tie Panels to create a feed and tack alley.
- Available in 36", 48", and 60" widths
Houston Cattle Tie Panel Alley Control Cross Brace
$101.00
- Stabilizes feed alley
- 2 sizes of stubs to stack cross braces.
Fair & Expo Horse Stalls price list
Portable Horse Stalls
CALL
- 1.5" OD 14 gauge tubing
- Available in 10' and 12' stall front and dividers.
- 4' Hinged door
- Dividers available with verticals or solid sheeting
- Sheeting is 3/4" BB plyform filler.
Wyoming Stalls
CALL
- 1.9" OD 16 gauge tubing
- Available in 10' and 12' stall front and dividers.
- 4' Rolling door
- Dividers available with verticals or solid sheeting
- Sheeting is 3/16" HDPE filler.
